UNIT SPECIFICATIONS

SCRUBBER

• Scrubber type - specify all that apply: Axial
• Scrubber volume (Kg): 2.7kg
• Temperature stick (scrubber monitoring): No
• Scrubber duration CE: CO2 1.6l/m 5mb bypass — TBC

LOOP

• Work Of Breathing (WOB): CE 100m test, trimix, horizontal — TBC
• Work of Breathing (WOB): CE 40m test, Air, vertical — 1.6 joules/Litre
• Active loop volume (liter): CE Test
• Counterlung volume (liters) - options?
• Backmounted Counterlung: No
• Frontmounted Counterlungs: Yes
• Detachable counterlungs (w/o unit disassembly): Yes
• Oxygen injection side: Before Scrubber
• Loop direction: Right to left
• Automatic Diluent Valve: Yes
• Diluent Shut-off Valve: No
• Bail Out valve (BOV): Yes (Built into the ADV system)
• Mouthpiece Retaining Strap: No
• Flood Resistant - specify: Exhalation Lung has purgable water trap.
• All electronics sealed from water ingress

HEAD & SENSORS

• Plug and Play Head Components - user replaceable? No
• User Upgradeable Firmware: Yes
• Number of O2 cells - options(?) 3 (2 × Analogue + 1 × Solid state or 3 × Analogue)
• Number of solenoids: 1
• Means of O2 addition (solenoid only, leaky valve, hybrid): Solenoid + MAV
• Solid state O2 sensor: Yes, Greenflash
• Independent secondary O2 reading: N/A
• Oxygen cell tester (>1bar). Specify built-in or add-on (pot): No
• Helium sensors: No
• Dual Computers: Yes
• Independent electronics (specify): 2 monitoring systems in the head, each with independent transmitters
• Battery type: Rechargeable
• Battery life dive time (hours): TBC

DISPLAYS & WARNINGS

• Heads Up Display: Fully featured dive computer HUD
• Buddy display: Optional wired HUD with buddy light
• Other Active Warning Devices: Vibrating Alert in Rebreather Head
• Near Eye Computer (HUD): Yes
